110 Polyester Industrial Screen Printing Silk Mesh For Textile Printing Cloth
Brief introduction of the polyester printing mesh:
The printing net belongs to a kind of wire mesh. The polyester printing net is made of polyester yarn and woven with a specific machine. The weaving method of polyester printing net is plain weave. Can be woven into different densities and specifications to meet the needs of different product printing.
Details of the printing mesh:
Material: 100% polyester
Certification:FDA,MSDS,ROSH,SGS,ISO 9001
Mesh: 110mesh ,from13T-165T
Thread diameter: 80 micron
Aperture:149 micron
Color: white ,and yellow
Advantages:
Reking Wire Mesh Co.,ltd have sold the screen printing mesh more than 21 years.
And we have our own factory.
Our clients come from more than 60 countries and regions.
We have hot sale specifications as below:
43T-80/ 54T-64/64T-55/90T-48/100T-40/120T-31/140T-34/150T-31/180T-27.
And our price is very reasonable,you will happy for this.
Our MOQ is 1 meter,if you want more the price will lower.
And if you want our mesh package can make mesh roll,we also can fold the mesh.
We can according to your clients requirement to provide mesh for you!
Specification of the polyester filter mesh:
| Mesh Count Diameter (Mesh/cm µm) | Mesh Count (Mesh/inch) | Weave | Aperture (µm) | Thread Diameter (µm) | Opening (%) | Thickness (µm) | Thickness Tollerance (+/- µm) | Theoretical Ink (cm3/m2) | Weight (g/m2 |
| 39-55PW(S) | 100 | 1:01 | 177 | 55 | 56 | 88 | 6 | 55 | 30 |
| 40-80PW(T) | 103 | 1:01 | 166 | 80 | 44 | 133 | 7 | 59 | 60 |
| 43-80PW(T) | 110 | 1:01 | 149 | 80 | 41 | 130 | 7 | 53 | 64 |
| 47-45PW(S) | 120 | 2:02 | 166 | 45*2 | 61 | 80 | 6 | 42 | 40 |
| 47-55PW(S) | 120 | 1:01 | 152 | 55 | 51 | 88 | 6 | 48 | 34 |
| 48-70PW(T) | 122 | 1:01 | 133 | 70 | 41 | 115 | 6 | 47 | 55 |
| 53-45PW(S) | 135 | 2:02 | 143 | 45*2 | 57 | 79 | 7 | 41 | 46 |
| 53-55PW(S) | 135 | 1:01 | 133 | 55 | 50 | 86 | 6 | 42 | 40 |
| 54-64PW(T) | 137 | 1:01 | 115 | 64 | 39 | 100 | 5 | 39 | 51 |
| 54-70PW(HD) | 137 | 1:01 | 109 | 70 | 35 | 116 | 6 | 40 | 62 |
| 61-64PW(T) | 155 | 1:01 | 90 | 64 | 31 | 101 | 5 | 30 | 58 |
| 64-55PW(S) | 160 | 1:01 | 98 | 55 | 38 | 98 | 5 | 36 | 48 |
| 64-64PW(T) | 160 | 1:01 | 85 | 64 | 30 | 115 | 6 | 34 | 61 |
| 68-55PW(S) | 175 | 1:01 | 85 | 55 | 34 | 85 | 4 | 28 | 48 |
| 68-64PW(T) | 175 | 1:01 | 78 | 64 | 28 | 105 | 5 | 30 | 65 |
| 72-48PW(S) | 182 | 1:01 | 90 | 48 | 36 | 78 | 5 | 33 | 39 |
| 72-55PW(T) | 182 | 1:01 | 85 | 55 | 30 | 90 | 5 | 27 | 51 |
| 77-48PW(S) | 195 | 1:01 | 77 | 48 | 35 | 80 | 4 | 28 | 42 |
| 77-55PW(T) | 195 | 1:01 | 67 | 55 | 27 | 88 | 4 | 24 | 55 |
| 80-48PW(T) | 200 | 1:01 | 72 | 48 | 33 | 74 | 4 | 25 | 56 |
| 90-48PW(T) | 230 | 1:01 | 56 | 48 | 25 | 78 | 4 | 19 | 50 |
| 100-40PW(T) | 255 | 1:01 | 58 | 40 | 33 | 63 | 3 | 21 | 37 |
| 110-40PW(HD) | 280 | 1:01 | 48 | 40 | 27 | 64 | 3 | 17 | 40 |
| 120-31PW(S) | 305 | 1:01 | 49 | 31 | 35 | 49 | 3 | 17 | 26 |
| 120-34PW(T) | 305 | 1:01 | 45 | 34 | 30 | 55 | 3 | 16 | 35 |
| 120-40PW(HD) | 305 | 1:01 | 37 | 40 | 20 | 63 | 3 | 13 | 44 |
| 130-34PW(T) | 330 | 1:01 | 40 | 34 | 27 | 55 | 3 | 15 | 37 |
| 140-31PW(S) | 355 | 1:01 | 36 | 31 | 26 | 48 | 2 | 12 | 30 |
| 140-34PW(T) | 355 | 1:01 | 31 | 34 | 20 | 53 | 3 | 10 | 39 |
| 140-34TW(T) | 355 | 2:01 | 33 | 34 | 21 | 56 | 3 | 12 | 41 |
| 150-31PW(S) | 380 | 1:01 | 32 | 31 | 23 | 49 | 3 | 11 | 32 |
| 150-34PW(T) | 380 | 1:01 | 23 | 34 | 13 | 55 | 3 | 6.5 | 42 |
| 165-31PW(S) | 420 | 1:01 | 23 | 31 | 15 | 48 | 2 | 7 | 36 |
| PW:(Plain Weave);TW:(Twill Weave); S T HD:(thickness of Mesh) |
| Standard Color: white and yellow, other colors on request. |
Application of the polyester mesh:
Except for liquids and gases, any object can be used as a substrate.
The specific can be divided into the following aspects. Paper printing. Printing of plastics. Printing of wood products. Printing of metal products. Printing of glass ceramics. Printing of signs. Printing of circuit boards. And printing and dyeing industries.
